Our Manufacturing Facilities
Infrastructure
- Facility: 6000 Square Feet building area
- Manpower: 80 Employees (Team of Highly Qualified and Experienced Skilled Engineers)
- CAD/CAM Software: Delcam
CNC Machines
| Make | Model | Country | Diameter x Length | Qty |
|---|---|---|---|---|
| ACE | JOBBER EXCEL | INDIA | 250x250 mm | 2 |
| ACE | SUPER JOBBER EXCEL | INDIA | 250x250 mm | 9 |
| LMW | Ll20TL3 | INDIA | 250x250 mm | 2 |
VMC Machines (For Machining and Dies/Mould)
| Make | Model | Country | X Travel | Y Travel | Z Travel | Feature | Qty |
|---|---|---|---|---|---|---|---|
| Haas | VF2 | USA | 650 mm | 550 mm | 500 mm | 1 | |
| ACE | MCV400 | INDIA | 650 mm | 550 mm | 500 mm | (4-axis)(Rotary) | 2 |
| ACE | MCV500 | INDIA | 800 mm | 550 mm | 500 mm | 1 | |
| LMW | LV-55 | INDIA | 700 mm | 550 mm | 550 mm | 2 |
Other Machinery
| Name | Qty |
|---|---|
| Toolroom Lathe | 6 |
| Toolroom Drill | 3 |
| Milling Machine | 1 |
CAD CAM Facility
Conventional Tool Room
Conventional Shop
Dispatch Area
Our Workshop
